Free Fall Gravity Pipeline Metal Detector For Plastic/Powder
Food/Flour Industry
Free Fall Gravity Pipeline Metal Detector for Plastic/Powder
Food/Fluor Industry
Feed tube diameter
| Yield | Sensitive :Fe : Cu: SUS: |
35MM
|
300KG/HR | Fe:0.3mm Cu:0.3 sus:0.8mm |
| 50MM |
800KG/HR | Fe:0.5mm Cu:0.5mm sus:1.0mm |
| 70MM | 1800KG/HR | Fe:0.8mm Cu:0.8mm sus:1.5mm |
| 100MM | 2500KG/HR | Fe:1.2mm Cu:1.2mm Sus:2.0mm |
| 150MM | 5000KG/HR | Fe:1.8mm Cu:1.8mm Sus:3.5mm |
Gravity type falling pipeline metal detector,
program specification of Gravity type falling pipeline metal
detector :
1. Test object: it must be a non-metallic substance, and its outer
packaging must also meet this requirement.
2. Detection purpose: detect the metal impurities in the tested
articles.
3. Industry scope: flour, sugar, chemicals, plastics, medicine and
other additive products,
The tested articles are mostly granular, powdery or liquid.
4. Usage: detect the product before packaging, usually install it
on the production pipeline, and put the unqualified product into
production
Products are automatically eliminated.
5. Anti deviation treatment of conveyor belt.
6. The detection coil and circuit components are imported
components.
7. Two independent transformers are used for power supply.
8. Strong shock and interference resistance.
Product features of Gravity type falling pipeline metal detector:
1. The whole machine is made of mirror stainless steel, which is
clean and not easy to stick ash.
2. The whole machine adopts laser cutting, and the manufacturing
process is exquisite.
3. The detection probe and electrical control box shall be
waterproof and dustproof.
4. The pipeline is easy to disassemble and clean.
ChangShu SanHe Precision Machinery & Technolgoy Co.,Ltd is a
technological enterprise which is professional engaged in research,
development, manufacture and sale of solid and powder product
(graininess product and powdery product ) packaging machine, liquid
filling machine, automatic packing(filling) and & palletizer line.
It’s products sell well home and abroad ,and are already widely
used in chemical,petrochemical, fine chemical, medicine,
fertilizer, plastics, rubber, dyestuff, food, feed, non-ferrous
metals, metallic minerals, nonmetallic minerals, building material
industries etc.
ChangShu SanHe Precision Machinery & Technolgoy Co.,Ltd is a
Jiangsu Province Hi-tech Enterprise, a Jiangsu Province Private
Science & Technology Enterprise, It is a patented advanced of
Jiangsu province. It won Chinese National Private Hi-tech
Enterprise Innovation Prize in 2006,
and be already awarded ISO9001-2000 “Certificate of The System of
Quality Certification” and “License for manufacturing measuring
instruments of the People’s republic of China”(CMC). it has three
Jiangsu Province Hi-tech Products . The enterprise has 104
employees , including 28 technicians.
