Premade Bag 5-50kg Weighing Packing Machine Palletizing Line For Wheat Seeds

Product Categories

Automatic Bagging Machine [111]
25Kg Bagging Machine [64]
Open Mouth Bagging Machine [88]
Valve Bagging Machine [57]
Big Bag Packing Machine [84]
Bulk Bag Unloader [18]
IBC Filling Machine [28]
Drum Filling Machine [18]
Automatic Palletizer Machine [18]
Industrial Bagging Machine [43]
Carbon Black Packing Machine [23]
Pellet Packing Machine [9]
Automatic Powder Packing Machine [29]
Auxiliary Equipment [82]
Automatic Pallet Wrapping Machine [10]

Changshu Sanhe Precision Machinery & Technology Co.,Ltd.

Contact Now

Premade Bag 5-50kg Weighing Packing Machine Palletizing Line For Wheat Seeds

Ask Lasest Price
Brand Name :	Sanhe
Model Number :	SanhePMT OAPL-400-25
Certification :	ISO9001:2015. CE
Price :	Negotiation
Payment Terms :	T/T,
Supply Ability :	3 Set Per Month
Delivery Time :	120-150 Days

Add to Cart

Product Details
Company Profile

Premade Bag 5-50kg Weighing Packing Machine Palletizing Line For Wheat Seeds

automatic 5kg to 50kg premade bag weighing packing palletizing line for wheat seeds

Production process:

Automatic giving empty bag - automatic weighing - automatic filling - automatic sewing machine - automatic conveying -automatic robot palletizing stacking；

Feeding type	Arc door (can be determined according to materials)
Target weight	5kg-50kg per bag
Packing accuracy (tolerance)	Better than 0.1-0.2 % of full scale
Packing speed	400 bags / hour
power	380/220 V, 50-60Hz,3-phase, 5-wire
Bag size	L:500mm-1000mm, W:350mm-605mm
Bag material	Kraft paper laminating bag; Woven bag (coating); Plastic bag (film thickness 0.2mm); Woven bag (PE plastic bag laminating); etc. remarks :Woven bags and composite bags are required (weight per square meter on one side ≥ 140g)
Bag shape	Pillow shaped open mouth bag
Air supply Pressure	0.55~0.7 Mpa;
Air consumption:	0.3N m3 / min;
De-dusting negative pressure	10mba;
Air volume	1200m3 / hour

Equipment introduction:

The heavy bag weighing packing unit is mainly an automatic packing process of automatic bagging, automatic weighing materials, automatic filling materials and automatic sewing and output. Thus, the automatic operation from bulk materials to woven bag packaging is realized, which saves the investment of human, material and financial resources, reduces the production cost for customers and improves the production efficiency. The unit is widely used in the packging of powdery and granular materials such as feed, flour, chemical industry, grain, chemical fertilizer and building materials. It is the first choice for major companies to realize automatic packaging.

Equipment includes:

OAPL-25-400 automatic wheat seeds weighing packing machine (including operation platform);

Automatic empty bag loading machine;

Sewing machine;

Conveyor;

Bag shaking shaping machine;

Weight re-checking machine;

Knockout machine；

Buffer conveyor；

Bag grabbing conveyor；

Pallet magazinze；

Palletizing (including protective fence);

Safety guardrail and pull rope switch;

Control cabinet;

We have more than tens of seed company customers；

ChangShu SanHe Precision Machinery & Technolgoy Co.,Ltd is a Jiangsu Province Hi-tech Enterprise, a Jiangsu Province Private Science & Technology Enterprise, It is a patented advanced of Jiangsu province. It won Chinese National Private Hi-tech Enterprise Innovation Prize in 2006,

and be already awarded ISO9001-2000 “Certificate of The System of Quality Certification” and “License for manufacturing measuring instruments of the People’s republic of China”(CMC). it has three Jiangsu Province Hi-tech Products . The enterprise has 104 employees , including 28 technicians.

Part of our customers :

EVONIK,WACKER,BAYER,ELIOKEM,SOLVAY,BASF,LANXESS,DANISCO,LYNAS,HUBER,RHODIA
