DCS-25V Sanhe PMT Dry Mortar Weighing And Packing Machine With Gravity Vibration Feeder

Ask Lasest Price
Brand Name :	Sanhe
Model Number :	DCS-25V
Certification :	ISO9001:2015, CE
Price :	Negotiable
Payment Terms :	T/T
Supply Ability :	30 Sets Per Month
Delivery Time :	Negotiable

Add to Cart

Product Details
Company Profile

DCS-25V Sanhe PMT Dry Mortar Weighing And Packing Machine With Gravity Vibration Feeder

DCS-25(GO7N)Net Weight Type for Granules 25 Kg Packing Scale Machine 1

A. What is the 25 kg packing machine ?

It is used to transport materials (normally powder or granule ) from the silo to the packaging container, and it also has the function of weighing,

B. Discription of 25 Kg packing machine ?

Electronic quantitative packaging scale is a combination of electronic scale and automatic control. It weighs when feeding until it is close to the preset packaging value. The computer quantitative packing scale is composed of several independent weighing units with the structure of feeding and discharging. The computer quantitative packing scale is suitable for the quantitative packing of 25kg-50kg, and the electronic quantitative packing scale is widely used.

C. Application of 25Kg packing machine:

Powder quantitative packaging machine is suitable for the quantitative packaging of powder, powder and powder materials in chemical, food, agricultural and sideline products industries, such as milk powder, starch, pesticide, veterinary medicine, premix, additive, condiment, feed, enzyme preparation, etc.; powder quantitative packaging machine is a combination of machine and instrument, controlled by single chip microcomputer, with automatic quantitative, automatic filling and automatic adjustment of measurement error Etc.

D. According to the different styles of packaging bags, it can be divided into open mouth bag packing machine and valve type bag packing machine

	DCS-25V
Scope of application of our Packing Machine :
Suitable materials	Granule and powder material with good flowability
Bag	Valve bag(automatic sealing bag)
Feeding type	Gravity
Alternative feeding type	Vibration
Technical parameters
Automatic supply bag machine	1
Number of packing scale	1
Feeding mouth	2
One swing bag can with maximum feeding mouth number	2
Weighing range(Kg)	25
Packing speed(bag/H)	200-600
Packing Accuracy	Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)

Suitable for : automatic packing for granular and powdery materials (use valve type bags)

Product Characteristics :
Easy to operate and use

Bag-clamp equipment is advanced, material can be fully filled

Fill material system has material-stop equipment, accuracy high

Control, work parts all use imported parts, stable and reliable with sewing machine

Heat-sealing machine optional

Features & advantages :
1. Good service
2. Fast delivery
3. PLC technology of electronically automatic measurement , accurate measurement, dust free.
4. High packing speed
5. Reliable and durable, long lifecycle of spare parts.
6. Firm, durable & easy to use
7. Suitable for powder, granule and clump.
8. Various of types/colors/size/specifications for selection
9. Hot sold by manufacturer/support OEM and ODM with good quality & price
10. Customer first, integrity highest

Our core products are:

Automatic open mouth bag packing and palletizing line

Automatic valve bag packing and palletizing line

Automatic packing and palletizing line

Open mouth bag packing machine for granular

Open mouth bag packing machine for powder

Valve bag packing machine for granular

Valve bag packing machine for powder

Big bag packing machine

Big bag unloading station

Liquid filling machine

Various conveyors

Exhibition:

	DCS-25GO7N) net weight type for granules	DCS-25(PO2G) Gross weight type for granules	DCS-25(PO2N) Net weight type for powder	DCS-25(PO4G) Vertical screw type
Scope of application
Suitable materials	Granular material or powder material with fine flowability	powder material or Fine powder	powder material	Easy to bridging or raised dust of ultrafine powder
Suitable packing container	Open mouth bag, box, barrel	Open mouth bag, box, barrel	Open mouth bag, box, barrel	Open mouth bag, box, barrel
Feeding type	Gravity	horizontal screw	horizontal screw	Vertical screw
Alternative feeding type	Vibrator	Vibrator, belt	Vibrator, belt	×
Technical parameters
Weighing range	1-100	10-50	10-50	1-50
Packing speed(bag/H)	300-800	100-200	100-500	100-180
Packing Accuracy	Generally (+/- )0.2% ( Note: special materials shall depend on the industrial standard )
Control function
Automatic tare	○	○	○	○
Automatic quick and slow feeding	○	○	○	○
Automatic free fall compensation	○	○	○	○
Automatic minus deviation	▲	▲	▲	▲
Automatic over weight alarms	○	○	○	○
diagnosis failure	○	○	○	○
Manual/Automatic mode conversation	○	○	○	○
Communication port	▲	▲	▲	▲
Regulatory function
Manual adjusting the height of bag	○	○	○	○
Important auxiliary function
Arch break function of hopper	×	○	○	○
Vibration at the bottom of the bag	▲	▲	▲	▲
Powder protection
Inflatable seal	▲	▲	▲	▲
Negative pressure dusting(not contain duster)	▲	○	○	○
Valve for leak-proof	×	▲	▲	▲
Safety protection
Electrostatic grounding	▲	▲	▲	▲
ionic wind remove static	▲	▲	▲	▲
when lose power	○	○	○	○
Emergency stop	○	○	○	○
Ex-proof	▲	▲	▲	▲
Original mode	DCS-25	DCS-25FW	DCS-25F	DCS-25FL
Mark: “○”is standard function；“▲”is choose function ；“×”is not has function

Main specialty

Scope of application: Granular material or powder material of Packing bags(boxes and pails)
Can be made into twin-type pakcer(except DCS-25(GO7N)和DCS-25(PO4G))
Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.
