DCS-25FWG Automatic Bagging Machine Open Top Bag Weighing Packing
Machine
A. What is the 25 kg packing machine ?
It is used to transport materials (normally powder or granule )
from the silo to the packaging container, and it also has the
function of weighing,
B. Discription of 25 Kg packing machine ?
Electronic quantitative packaging scale is a combination of
electronic scale and automatic control. It weighs when feeding
until it is close to the preset packaging value. The computer
quantitative packing scale is composed of several independent
weighing units with the structure of feeding and discharging. The
computer quantitative packing scale is suitable for the
quantitative packing of 25kg-50kg, and the electronic quantitative
packing scale is widely used.
C. Application of 25Kg packing machine:
Powder quantitative packaging machine is suitable for the
quantitative packaging of powder, powder and powder materials in
chemical, food, agricultural and sideline products industries, such
as milk powder, starch, pesticide, veterinary medicine, premix,
additive, condiment, feed, enzyme preparation, etc.; powder
quantitative packaging machine is a combination of machine and
instrument, controlled by single chip microcomputer, with automatic
quantitative, automatic filling and automatic adjustment of
measurement error Etc.
D. According to the different styles of packaging bags, it can be
divided into open mouth bag packing machine and valve type bag
packing machine
The parameter and function :
| DCS-25FWG ( PO1G-S ) Bagging Machine |
| Scope of application |
| Suitable materials | Powder and thin granule of good Air affinity |
| Suitable packing container | Open mouth bag |
| Feeding type | Above and below the two screws |
| Alternative feeding type | × |
| Technical parameters |
| Weighing range(Kg) | 5-50 |
| Packing speed(bag/H) | 30-100 |
| Packing Accuracy | Generally (+/- )0.2%(Note: special materials shall depend on the
industrial standard) |
Product Characteristics :
Designed with touch screen control and has much simplicity in its
use. In addition, you can make adjustment on packaging sizes
according to your needs.
Our Service :
1. We can provide "one-stop purchasing" or "package program" system
solutions and owns professional manufacturing equipment as well as
a full range of technical support and after-sale service.
2. OEM, Customized can be all accepted.
3. Contact us any time when you feel free.
FAQ :
Q: Can your machine be customized ?
A: Yes, we are a professional manufacturer specilized in
palletizing robot, packaging machine, conveyor etc. for more than
20 years and we have a strong design & technical team. We can
design and manufacture as per your requirements.
Minimum order quantity: 1 set, FOB Shanghai
Warranty: 12 months following delivery. We offer online service 24
hours all day long.
You can contact us any time, if urgently, please call us.
Open Mouth Bag Suction Packer
The parameter and function table of the Open Mouth Bag Exhaust Packer
| | DCS-25(P01G-S)
(positive pressure Exhausting) | DCS-25(PO3G-S)
(negative pressure Exhausting) |
Scope of application |
Suitable materials |
Powder and thin granule of good Air affinity |
Powder and thin granule of good Air affinity |
Suitable packing container |
Open mouth bag |
Open mouth bag |
Feeding type |
Above and below the two screws |
Air flow type |
Alternative feeding type | × |
Screw type |
Technical parameters |
| Weighing range (Kg) | 5-50 | 5-50 |
Packing speed(bag/H) | 30-100 | 30-100 |
| Packing Accuracy |
Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard) |
Control function |
Automatic tare | ○ | ○ |
Automatic quick and slow feeding | ○ | ○ |
Automatic free fall compensation | ○ | ○ |
Automatic minus deviation | ▲ | ▲ |
Automatic over weight alarms | ○ | ○ |
Automatic self diagnosis failure | ○ | ○ |
Manual/Automatic mode conversation | ○ | ○ |
Communication port | ▲ | ▲ |
Regulatory function |
Manual adjusting the height of bag | ○ | ○ |
Important auxiliary function |
positive pressure Exhausting function | × | ○ |
negative pressure Exhausting function | ○ | × |
Arch break function of hopper | ▲ | ▲ |
Vibration at the bottom of the bag | ▲ | ▲ |
Powder protection |
Inflatable seal | ▲ | ▲ |
Negative pressure dusting(not contain duster) | ▲ | ▲ |
Valve for leak-proof | × | ○ |
Safety protection |
Electrostatic grounding | ▲ | ▲ |
ionic wind remove static | ▲ | ▲ |
Stop packing when lose power | ○ | ○ |
Emergency stop | ○ | ○ |
Ex-proof | ▲ | ▲ |
Mark: “○”is standard function；“▲”is choose function ；“×”is not has
function |
Main specialty
*Suit for material contain many air which use open mouth bag to
packing.
*Can exhausting the air in material, improve the bulk density of material in bag. It not wasting material.
*Can made into semi-packing and palletizing line with conveyors,
sewing machine, heat sealer, fall bag conveyor, reshaping conveyor,
weight checker, reject conveyor, pallet magazine, stacker.
