    Digital Quantitative 25 Kg Bag Packing Machine

    Ask Lasest Price
    Brand Name : Sanhe
    Model Number : DCS-25
    Certification : ISO9001:2015, CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 90 Sets Per Month
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Digital Quantitative 25 Kg Bag Packing Machine

    Digital Quantitative 25 Kg Bag Packing Machine

    DCS-25(GO7N)Net Weight Type for Granules 25 Kg Packing Scale Machine 0

    DCS-25(GO7N)Net Weight Type for Granules 25 Kg Packing Scale Machine 1


    The parameter and function table :

    DCS-25(GO7N) Net weight type for granules
    Scope of application
    Suitable materialsGranular material or powder material with fine flowability
    Suitable packing containerOpen mouth bag, box, barrel
    Feeding typeGravity
    Alternative feeding typeVibrator
    Technical parameters
    Weighing range(Kg)25 Kg
    Packing speed(bag/H)Packing speed 160-180bag/H(Gross weight) 200-300bags/H(Net weight)
    Packing AccuracyGenerally (+/- )0.2%(Note: special materials shall depend on the industrial standard)

    FAQ .
    Please Send us The Details We Required :
    1. Name of Material to Be Filled in Bag?
    2. Weight Capacity of Single Bag ?
    3. How Much Bag Fill Per Hour?
    4. Your Materials Characte?



    DCS-25GO7N)

    net weight type for granules

    DCS-25(PO2G)

    Gross weight type for granules

    DCS-25(PO2N)

    Net weight type for powder

    DCS-25(PO4G)

    Vertical screw type


    Scope of application


    Suitable materials


    Granular material or powder material with fine flowability


    powder material or Fine powder


    powder material


    Easy to bridging or raised dust of ultrafine powder


    Suitable packing container


    Open mouth bag, box, barrel


    Open mouth bag, box, barrel


    Open mouth bag, box, barrel


    Open mouth bag, box, barrel


    Feeding type


    Gravity


    horizontal screw


    horizontal screw


    Vertical screw


    Alternative feeding type


    Vibrator


    Vibrator, belt


    Vibrator, belt

    ×

    Technical parameters


    Weighing range

    1-10010-5010-501-50

    Packing speed(bag/H)

    300-800100-200100-500100-180

    Packing Accuracy


    Generally (+/- )0.2% ( Note: special materials shall depend on the industrial standard )


    Control function


    Automatic tare


    Automatic quick and slow feeding


    Automatic free fall compensation


    Automatic minus deviation

    Automatic over weight alarms

    diagnosis failure


    Manual/Automatic mode conversation


    Communication port


    Regulatory function

    Manual adjusting the height of bag

    Important auxiliary function

    Arch break function of hopper

    ×

    Vibration at the bottom of the bag

    Powder protection

    Inflatable seal

    Negative pressure dusting(not contain duster)

    Valve for leak-proof

    ×

    Safety protection

    Electrostatic grounding

    ionic wind remove static

    when lose power

    Emergency stop

    Ex-proof

    Original mode

    DCS-25DCS-25FWDCS-25FDCS-25FL

    Mark: “○”is standard function;“▲”is choose function ;“×”is not has function


    Main specialty

    • Scope of application: Granular material or powder material of Packing bags(boxes and pails)
    • Can be made into twin-type pakcer(except DCS-25(GO7N)和DCS-25(PO4G))
    • Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.
