Valve Packer Weighing Filling 25 Kg Automatic Bagging Machine

    Buy cheap Valve Packer Weighing Filling 25 Kg Automatic Bagging Machine from wholesalers

    Buy cheap Valve Packer Weighing Filling 25 Kg Automatic Bagging Machine from wholesalers
    • Buy cheap Valve Packer Weighing Filling 25 Kg Automatic Bagging Machine from wholesalers

    Valve Packer Weighing Filling 25 Kg Automatic Bagging Machine

    Ask Lasest Price
    Brand Name : Sanhe
    Model Number : DCS-25
    Certification : ISO9001:2015, CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 90 Sets Per Month
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Valve Packer Weighing Filling 25 Kg Automatic Bagging Machine

    DCS-25PV3 Valve Bagging Packer Machine Weighing Packing Scale Filling With Fast Speed



    A. What is the 25 kg packing machine ?
    It is used to transport materials (normally powder or granule ) from the silo to the packaging container, and it also has the function of weighing,


    B. Application of 25Kg packing machine:
    Powder quantitative packaging machine is suitable for the quantitative packaging of powder, powder and powder materials in chemical, food, agricultural and sideline products industries, such as milk powder, starch, pesticide, veterinary medicine, premix, additive, condiment, feed, enzyme preparation, etc.; powder quantitative packaging machine is a combination of machine and instrument, controlled by single chip microcomputer, with automatic quantitative, automatic filling and automatic adjustment of measurement error Etc.


    The parameter and function table :

    DCS-25PV3
    Scope of application
    Suitable materialsPowder and thin granule
    Suitable packing containervalve bag
    Feeding typeGravity
    Alternative feeding typeVibrator
    Technical parameters
    Weighing range(Kg)25 kg
    Packing speed(bag/H)80-120 bag / H ( Gross weight ) 200-300 bags / H ( Net weight )
    Packing AccuracyGenerally ( +/- ) 0.2% FS, 2δ ( Note : special materials shall depend on the industrial standard )

    Technological process of the equipment

    Automatic lifting materials→Automatic weighing machine → Automatic bag packaging unit (pick up bags, welt bags, clamp bags, open bags, blank) →Horizontal automatic sealing machine unit (automatic conveying, sealing bags, cut lines) → Finished product output → Automatic conveying


    Valve Bag Packer


    The parameter and function table of the valve bag packer:

    DCS-25PV1(1)

    (exhausting type)

    DCS-25PV1(2)

    (screw type)

    DCS-25PV1(3)

    (airflow type)

    DCS-25PV1(5)

    (horizontal impeller)

    DCS-25PV1(6)

    (vertiacl impeller)


    Scope of application


    Suitable materials


    Powder and ultrafine powder of good Air affinity


    Powder and thin granule


    Powder and thin granule


    Powder and ultrafine powder


    Powder and ultrafine powder


    Suitable packing container

    Upper and lower spiral air supplysingle screwair flowHorizontal impellerVertical impeller

    Technical parameters


    Weighing range(Kg)

    10-5010-5010-5010-5010-50

    Packing speed(bag/H)

    30-18030-12030-20030-25030-250

    Packing Accuracy


    Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)


    Control function


    Automatic tare


    Automatic quick and slow feeding


    Automatic free fall compensation


    Automatic minus deviation

    ××

    Automatic over weight alarms


    Automatic self diagnosis failure


    Manual/Automatic mode conversation


    Communication port


    Regulatory function


    Manual adjusting the height of bag


    Suit for open and valve bag function


    Important auxiliary function


    Blow bag function in advance


    Arch break function of hopper


    Vibration at the bottom of the bag


    Powder protection


    Inflatable seal

    ×××

    Negative pressure dusting(not contain duster)


    Automatic blow valve mouth

    ×

    Safety protection


    Electrostatic grounding


    ionic wind remove static


    Stop packing when lose power


    Emergency stop


    Ex-proof


    Mark: “○”is standard function;“▲”is choose function ;“×”is not has function


    main features:

    *valve bag packing for Powder and ultrafine powder.

    *Can be twin-type packer

    *Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.
