25 Kg White Carbon black packing machines bagging scale machine air packer

A. What is the DCS-25PV3 White Carbon black packing machines ?

It is used to transport materials (normally powder or granule ) from the silo to the packaging container, and it also has the function of weighing,

B. Discription of DCS-25PV3 White Carbon black packing machines ?

Electronic quantitative packaging scale is a combination of electronic scale and automatic control. It weighs when feeding until it is close to the preset packaging value. The computer quantitative packing scale is composed of several independent weighing units with the structure of feeding and discharging. The computer quantitative packing scale is suitable for the quantitative packing of 25kg-50kg, and the electronic quantitative packing scale is widely used.

Technical data :

	DCS-25PV3 ( airflow type ) White​ Carbon black
Scope of application
Suitable materials	Powder and thin granule / White Carbon black
Suitable packing container	valve type bag
Technical parameters
Weighing range(Kg)	25kg
Packing speed(bag/H)	80-120 bags per hour
100Packing Accuracy	Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard) ; 50-200g @25kg/bag

part of our customers:

EVONIK

WACKER

BAYER

ELIOKEM

SOLVAY

BASF

LANXESS

DANISCO

LYNAS

Why choose us :

High Quality ---- Quality Raw Material, Advanced Facilities, Fine Procedures.

High Productivity

Fast Delivery

Leading Level R & D Department

Experienced Marketing Manager

Professional Design Department

Accept OEM & ODM of Valve Bag Machine

Engineer oversea service

95% of China silica ( white carbon black ) factory use our packing scale machine.

Valve Bag Packer

The parameter and function table of the valve bag packer:

	DCS-25PV1(1) (exhausting type)	DCS-25PV1(2) (screw type)	DCS-25PV1(3) (airflow type)	DCS-25PV1(5) (horizontal impeller)	DCS-25PV1(6) (vertiacl impeller)
Scope of application
Suitable materials	Powder and ultrafine powder of good Air affinity	Powder and thin granule	Powder and thin granule	Powder and ultrafine powder	Powder and ultrafine powder
Suitable packing container	Upper and lower spiral air supply	single screw	air flow	Horizontal impeller	Vertical impeller
Technical parameters
Weighing range(Kg)	10-50	10-50	10-50	10-50	10-50
Packing speed(bag/H)	30-180	30-120	30-200	30-250	30-250
Packing Accuracy	Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)
Control function
Automatic tare	○	○	○	○	○
Automatic quick and slow feeding	○	○	○	○	○
Automatic free fall compensation	○	○	○	○	○
Automatic minus deviation	▲	▲	▲	×	×
Automatic over weight alarms	○	○	○	○	○
Automatic self diagnosis failure	○	○	○	○	○
Manual/Automatic mode conversation	○	○	○	○	○
Communication port	▲	▲	▲	▲	▲
Regulatory function
Manual adjusting the height of bag	○	○	○	○	○
Suit for open and valve bag function	▲	▲	▲	▲	▲
Important auxiliary function
Blow bag function in advance	○	▲	○	○	○
Arch break function of hopper	○	○	○	○	○
Vibration at the bottom of the bag	○	○	○	○	○
Powder protection
Inflatable seal	▲	×	▲	×	×
Negative pressure dusting(not contain duster)	○	○	○	○	○
Automatic blow valve mouth	○	×	○	▲	▲
Safety protection
Electrostatic grounding	▲	▲	▲	▲	▲
ionic wind remove static	▲	▲	▲	▲	▲
Stop packing when lose power	○	○	○	○	○
Emergency stop	○	○	○	○	○
Ex-proof	▲	▲	▲	▲	▲
Mark: “○”is standard function；“▲”is choose function ；“×”is not has function

main features:

*valve bag packing for Powder and ultrafine powder.

*Can be twin-type packer

*Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.

Changshu Sanhe Precision Machinery & Technology Co., Ltd (originally Changshu Sanhe Measuring Equipment Factory) builded in 1998, was established in 1998 with registered capital of 13.8 million RMB.

The total people of the company is 104, of which 28 are engineers and technicians. Our company is a scientific and technological enterprise specializing in the research and development manufacture and sale of granular and powder packaging machine, liquid filling machine, batching system and automatic packaging (filling) palletizer production line.

Our products are well-selling both at home and abroad, and are widely used in chemical industry, petrochemical industry, fine chemical industry, fertilizer, plastics, rubber, dyes, pigments, food, feed, non-ferrous metals. Metal ore, non-metallic ore, building materials and other industries. Our company is good at dealing with hard-to-pack powder and implementing dustless packaging. Our technical level is in the leading level in the industry. Some of the technology (automatic powder packaging machine with automatic air-removing function) has reached the international advanced level.

Changshu Sanhe Precision Machinery & Technology Co., Ltd is a national high-tech enterprise, Jiangsu high-tech enterprise and Jiangsu private high-tech enterprise. It has a postgraduate workstation in Jiangsu Province, a research and development center of Suzhou automatic packaging and palletizing production line. It has also obtained a national innovation fund, two national key new products and three products are high-tech products in Jiangsu Province. It has obtained ISO Quality Management System Certificate and CMC, and has a perfect after-sales service system. It has obtained 20 national patents, including 12 invention patents. The company also has the right of independent import and export trade.

Annual sales volume is RMB 71,000,000 in 2022.
