DCS-25PV1(7) Fast Weighing Packing Machine 25 Kg Packing Scale
200-600 Bags Per Hour
A. What is the 25 kg packing machine ?
It is used to transport materials (normally powder or granule )
from the silo to the packaging container, and it also has the
function of weighing,
B. Discription of 25 Kg packing machine ?
Electronic quantitative packaging scale is a combination of
electronic scale and automatic control. It weighs when feeding
until it is close to the preset packaging value. The computer
quantitative packing scale is composed of several independent
weighing units with the structure of feeding and discharging. The
computer quantitative packing scale is suitable for the
quantitative packing of 25kg-50kg, and the electronic quantitative
packing scale is widely used.
C. Application of 25Kg packing machine:
Powder quantitative packaging machine is suitable for the
quantitative packaging of powder, powder and powder materials in
chemical, food, agricultural and sideline products industries, such
as milk powder, starch, pesticide, veterinary medicine, premix,
additive, condiment, feed, enzyme preparation, etc.; powder
quantitative packaging machine is a combination of machine and
instrument, controlled by single chip microcomputer, with automatic
quantitative, automatic filling and automatic adjustment of
measurement error Etc.
D. According to the different styles of packaging bags, it can be
divided into open mouth bag packing machine and valve type bag
packing machine
The packing range is 10-50 kg / bag. For open mouth bag, the
machine has belt conveyor and sewing machine with itself. It's
convenient to sealing the bags. If you need, we also can provide
heat sealing machine.
For valve bag, there is semi-automatic type and automatic type,
when it's semi-automatic type, just put the valve mouth onto the
outlet of valve bag packing machine, then push a button, the
machine can clamp the bag then feed the material into bag and weigh
it automatically, when it's finish, the clamp will loose and the
bag will fall onto the belt conveyor.
For automatic type, we have bag applicator. Just put a pile of bags
near the machine, the simple robot will take the bag and put onto
the outlet of the machine.
Main specialty of our Packing Machine :
Valve Bag Automatic Packing & Palletizing Line for granule and
powder material.
Valve Bag Automatic Packing & Palletizing Line of our Packing Machine :
| DCS-25PV1(7)-MU-AL(multi-scales for granule) |
Scope of application |
Suitable materials | Granule and powder material with good flowability |
Bag | Valve bag(automatic sealing bag) |
Feeding type | Gravity |
Alternative feeding type | Vibration |
Technical parameters |
Automatic supply bag machine | 1 |
Number of packing scale | 1 |
Feeding mouth | 2 |
One swing bag can with maximum feeding mouth number | 2 |
Weighing range(Kg) | 25 |
Packing speed(bag/H) | 200-600 |
Packing Accuracy | Generally (+/- )0.2%(Note: special materials shall depend on the
industrial standard) |
Q: Payment terms, MOQ, warranty, Trade Terms
A: Payment terms: 30% down payment against order by T/T, the
balance of 70% to be paid on delivery.
Minimum order quantity: 1 set, FOB Shanghai
Warranty: 12 months following delivery. We offer online service 24
hours all day long
You can contact us any time, if urgently, please call us.
Q: What’s the package ?
A: Most of goods are packed on wooden pallet
Q: Do you offer Installation & debugging?
A: Our engineers are available to service machinery overseas to
help customers to solve machine problems.Relevant fees need to be
paid
Q: What’s policy for guarantee and broken parts ?
A: As for machine products, our company provides 12 months for all
mechanical parts with the exception of electrical and electronic
parts and those subjects to normal wear and tear. Meanwhile, the
guarantee starts from the shipment (B/L date). The guarantee is
intended limited to the replacement of the broken part after
checking the construction fault. The inspection of the causes of
the trouble or the breakdown of the parts is exclusively up to the
manufacturing company. All in all, our company can offer you
assured products.
Our core products are:
Automatic open mouth bag packing and palletizing line
Automatic valve bag packing and palletizing line
Automatic packing and palletizing line
Open mouth bag packing machine for granular
Open mouth bag packing machine for powder
Valve bag packing machine for granular
Valve bag packing machine for powder
Big bag packing machine
Big bag unloading station
Liquid filling machine
Various conveyors
